An Advanced Electrode for highest Quality Welding of Carbon Steels to Molybdenum-Containing Austenitic Stainless Steel of type AISI 316 Mo and Equivalent Grades.
Principal Applications:
For joining and cladding applications on 18 Cr/ 12 Ni/ 2 Mo type stainless steels, and to deposit the ‘barrier’ layer for Molybdenum – containing stainless overlays on carbon steels.
Typical All-weld Chemistry (Wt%)
| C | Mn | Si | Cr | Ni | S | P | Cu | |
| 0.04 | 0.80 | 0.30 | 22.5 | 13.00 | 0.02 | 0.03 | 0.20 |
| Mo |
| 2.50 |
Typical Mechanical Properties:
Tensile Strength : 580 MPa
Elongation (L=4D) : 35%
